Brass Inserts

Brass Inserts

DD Metal Group is Manufacturer, Exporter of Various Brass Inserts based at India (Jamnagar, Gujarat). DD Metal Group is a leading manufacturer of Brass Inserts for CPVC - UPVC Fittings.

Our Product suits for all type of Plastic Molding and injection molding Industries. We have established a large client base that extends to the worldwide markets because of our quality control. We offer a full line of brass inserts/brass adaptors for all methods of installation, including: press-in and mold-in. Although we produce various brass inserts as per custom design & specification.

Product Range:

Brass Molding Inserts

Brass Knurling Inserts

Brass CPVC Fittings

Brass UPVC Fittings

Brass PPR Fittings

Brass Threaded Inserts, Brass Round Inserts, Brass Hexagonal Inserts etc

Special Features of Brass Inserts/Brass Fittings:

Threads as per International Go & Not Go Standards.

Deep Groove for maximum Pull out Resistance.

Inner Diameter (I/D) after Threads with very close tolerance to prevent unnecessary flush to enter into the inserts.

Material:

Free Cutting Brass IS 319 Type (I) or

Free Cutting Brass as per BS 249 Type (I) or

High Grade Free Cutting Brass.

Any Special Brass Material Composition as per customer’s requirement.

Threads:

ISO metric (MM threads)

BSP for female inserts & BSPT for male inserts.

Or any threads as per custom specification can be developed.

UNC & UNF threads

Any Other as per specification

Threads as per International Go & Not Go Standards.

Knurling Available:

Diamond, Straight, Left and Right and through inserts are available.

Finishing and Plating:

Natural, Nickel Platted, Chrome Platted or any coating as per customer’s requirement.

Any Kind of Brass Gas Parts can be developed and supplied exactly as per customer’s specifications.
